Nano

CEILING RECESSED

Nano is an exercise in formal synthesis that redraws the boundaries of technical lighting, offering maximum light output with minimum use of raw materials.

Nano Recessed

Nano Trimless

Nano Tilt

Nano Recessed

Luminous flux

570 lm / 600 lm / 625 lm / 640 lm
Lighting efficiency

76% / 84%
Power

5,5 W
Dimming

No Dim, DALI
Colour temperature

2700K / 3000K / 3500K / 4000K
Sealing

IP20
Chromatic stability

MacAdam Step 2
Recess measurements

Ø30mm
Light beam angle

18° / 34°

EPD Instructions BIM Brochure

Luminous Flux

Select

Power

Select

Colour temperature

Select

Lighting efficiency

Select

CRI

Light beam angle

Dimming

Sealing

Cord length

Distance of suspension

Base Finishing

Colour

Model

Ref.

Colour

Source

Lum. flux

Power

Temp.

CRI

Beam angle

Efficiency

Dimming

Sealing
NANO RECESSED SPOT 2700K N

Reference:

A5390100N

Colour:

Black

Light source:

LED

Luminous flux:

570 lm

Power:

5,5 W

Colour temperature:

2700K

CRI:

CRI>90

Light beam angle:

18°

Lighting efficiency:

76%

Dimming:

No Dim

Sealing:

IP20
NANO RECESSED SPOT 2700K W

Reference:

A5390100W

Colour:

White

Light source:

LED

Luminous flux:

570 lm

Power:

5,5 W

Colour temperature:

2700K

CRI:

CRI>90

Light beam angle:

18°

Lighting efficiency:

76%

Dimming:

No Dim

Sealing:

IP20
NANO RECESSED SPOT 3000K N

Reference:

A5390101N

Colour:

Black

Light source:

LED

Luminous flux:

600 lm

Power:

5,5 W

Colour temperature:

3000K

CRI:

CRI>90

Light beam angle:

18°

Lighting efficiency:

76%

Dimming:

No Dim

Sealing:

IP20
NANO RECESSED SPOT 3000K W

Reference:

A5390101W

Colour:

White

Light source:

LED

Luminous flux:

600 lm

Power:

5,5 W

Colour temperature:

3000K

CRI:

CRI>90

Light beam angle:

18°

Lighting efficiency:

76%

Dimming:

No Dim

Sealing:

IP20
NANO RECESSED SPOT 3500K N

Reference:

A5390103N

Colour:

Black

Light source:

LED

Luminous flux:

625 lm

Power:

5,5 W

Colour temperature:

3500K

CRI:

CRI>90

Light beam angle:

18°

Lighting efficiency:

76%

Dimming:

No Dim

Sealing:

IP20
NANO RECESSED SPOT 3500K W

Reference:

A5390103W

Colour:

White

Light source:

LED

Luminous flux:

625 lm

Power:

5,5 W

Colour temperature:

3500K

CRI:

CRI>90

Light beam angle:

18°

Lighting efficiency:

76%

Dimming:

No Dim

Sealing:

IP20
NANO RECESSED SPOT 4000K N

Reference:

A5390102N

Colour:

Black

Light source:

LED

Luminous flux:

640 lm

Power:

5,5 W

Colour temperature:

4000K

CRI:

CRI>90

Light beam angle:

18°

Lighting efficiency:

76%

Dimming:

No Dim

Sealing:

IP20
NANO RECESSED SPOT 4000K W

Reference:

A5390102W

Colour:

White

Light source:

LED

Luminous flux:

640 lm

Power:

5,5 W

Colour temperature:

4000K

CRI:

CRI>90

Light beam angle:

18°

Lighting efficiency:

76%

Dimming:

No Dim

Sealing:

IP20
NANO RECESSED FLOOD 2700K N

Reference:

A5390110N

Colour:

Black

Light source:

LED

Luminous flux:

570 lm

Power:

5,5 W

Colour temperature:

2700K

CRI:

CRI>90

Light beam angle:

34°

Lighting efficiency:

84%

Dimming:

No Dim

Sealing:

IP20
NANO RECESSED FLOOD 2700K W

Reference:

A5390110W

Colour:

White

Light source:

LED

Luminous flux:

570 lm

Power:

5,5 W

Colour temperature:

2700K

CRI:

CRI>90

Light beam angle:

34°

Lighting efficiency:

84%

Dimming:

No Dim

Sealing:

IP20
NANO RECESSED FLOOD 3000K N

Reference:

A5390111N

Colour:

Black

Light source:

LED

Luminous flux:

600 lm

Power:

5,5 W

Colour temperature:

3000K

CRI:

CRI>90

Light beam angle:

34°

Lighting efficiency:

84%

Dimming:

No Dim

Sealing:

IP20
NANO RECESSED FLOOD 3000K W

Reference:

A5390111W

Colour:

White

Light source:

LED

Luminous flux:

600 lm

Power:

5,5 W

Colour temperature:

3000K

CRI:

CRI>90

Light beam angle:

34°

Lighting efficiency:

84%

Dimming:

No Dim

Sealing:

IP20
NANO RECESSED FLOOD 3500K N

Reference:

A5390113N

Colour:

Black

Light source:

LED

Luminous flux:

625 lm

Power:

5,5 W

Colour temperature:

3500K

CRI:

CRI>90

Light beam angle:

34°

Lighting efficiency:

84%

Dimming:

No Dim

Sealing:

IP20
NANO RECESSED FLOOD 3500K W

Reference:

A5390113W

Colour:

White

Light source:

LED

Luminous flux:

625 lm

Power:

5,5 W

Colour temperature:

3500K

CRI:

CRI>90

Light beam angle:

34°

Lighting efficiency:

84%

Dimming:

No Dim

Sealing:

IP20
NANO RECESSED FLOOD 4000K N

Reference:

A5390112N

Colour:

Black

Light source:

LED

Luminous flux:

640 lm

Power:

5,5 W

Colour temperature:

4000K

CRI:

CRI>90

Light beam angle:

34°

Lighting efficiency:

84%

Dimming:

No Dim

Sealing:

IP20
NANO RECESSED FLOOD 4000K W

Reference:

A5390112W

Colour:

White

Light source:

LED

Luminous flux:

640 lm

Power:

5,5 W

Colour temperature:

4000K

CRI:

CRI>90

Light beam angle:

34°

Lighting efficiency:

84%

Dimming:

No Dim

Sealing:

IP20
NANO RECESSED SPOT DALI 2700K N

Reference:

A5390200N

Colour:

Black

Light source:

LED

Luminous flux:

570 lm

Power:

5,5 W

Colour temperature:

2700K

CRI:

CRI>90

Light beam angle:

18°

Lighting efficiency:

76%

Dimming:

DALI

Sealing:

IP20
NANO RECESSED SPOT DALI 2700K W

Reference:

A5390200W

Colour:

White

Light source:

LED

Luminous flux:

570 lm

Power:

5,5 W

Colour temperature:

2700K

CRI:

CRI>90

Light beam angle:

18°

Lighting efficiency:

76%

Dimming:

DALI

Sealing:

IP20
NANO RECESSED SPOT DALI 3000K N

Reference:

A5390201N

Colour:

Black

Light source:

LED

Luminous flux:

600 lm

Power:

5,5 W

Colour temperature:

3000K

CRI:

CRI>90

Light beam angle:

18°

Lighting efficiency:

76%

Dimming:

DALI

Sealing:

IP20
NANO RECESSED SPOT DALI 3000K W

Reference:

A5390201W

Colour:

White

Light source:

LED

Luminous flux:

600 lm

Power:

5,5 W

Colour temperature:

3000K

CRI:

CRI>90

Light beam angle:

18°

Lighting efficiency:

76%

Dimming:

DALI

Sealing:

IP20
NANO RECESSED SPOT DALI 3500K N

Reference:

A5390203N

Colour:

Black

Light source:

LED

Luminous flux:

625 lm

Power:

5,5 W

Colour temperature:

3500K

CRI:

CRI>90

Light beam angle:

18°

Lighting efficiency:

76%

Dimming:

DALI

Sealing:

IP20
NANO RECESSED SPOT DALI 3500K W

Reference:

A5390203W

Colour:

White

Light source:

LED

Luminous flux:

625 lm

Power:

5,5 W

Colour temperature:

3500K

CRI:

CRI>90

Light beam angle:

18°

Lighting efficiency:

76%

Dimming:

DALI

Sealing:

IP20
NANO RECESSED SPOT DALI 4000K N

Reference:

A5390202N

Colour:

Black

Light source:

LED

Luminous flux:

640 lm

Power:

5,5 W

Colour temperature:

4000K

CRI:

CRI>90

Light beam angle:

18°

Lighting efficiency:

76%

Dimming:

DALI

Sealing:

IP20
NANO RECESSED SPOT DALI 4000K W

Reference:

A5390202W

Colour:

White

Light source:

LED

Luminous flux:

640 lm

Power:

5,5 W

Colour temperature:

4000K

CRI:

CRI>90

Light beam angle:

18°

Lighting efficiency:

76%

Dimming:

DALI

Sealing:

IP20
NANO RECESSED FLOOD DALI 2700K N

Reference:

A5390210N

Colour:

Black

Light source:

LED

Luminous flux:

570 lm

Power:

5,5 W

Colour temperature:

2700K

CRI:

CRI>90

Light beam angle:

34°

Lighting efficiency:

84%

Dimming:

DALI

Sealing:

IP20
NANO RECESSED FLOOD DALI 2700K W

Reference:

A5390210W

Colour:

White

Light source:

LED

Luminous flux:

570 lm

Power:

5,5 W

Colour temperature:

2700K

CRI:

CRI>90

Light beam angle:

34°

Lighting efficiency:

84%

Dimming:

DALI

Sealing:

IP20
NANO RECESSED FLOOD DALI 3000K N

Reference:

A5390211N

Colour:

Black

Light source:

LED

Luminous flux:

600 lm

Power:

5,5 W

Colour temperature:

3000K

CRI:

CRI>90

Light beam angle:

34°

Lighting efficiency:

84%

Dimming:

DALI

Sealing:

IP20
NANO RECESSED FLOOD DALI 3000K W

Reference:

A5390211W

Colour:

White

Light source:

LED

Luminous flux:

600 lm

Power:

5,5 W

Colour temperature:

3000K

CRI:

CRI>90

Light beam angle:

34°

Lighting efficiency:

84%

Dimming:

DALI

Sealing:

IP20
NANO RECESSED FLOOD DALI 3500K N

Reference:

A5390213N

Colour:

Black

Light source:

LED

Luminous flux:

625 lm

Power:

5,5 W

Colour temperature:

3500K

CRI:

CRI>90

Light beam angle:

34°

Lighting efficiency:

84%

Dimming:

DALI

Sealing:

IP20
NANO RECESSED FLOOD DALI 3500K W

Reference:

A5390213W

Colour:

White

Light source:

LED

Luminous flux:

625 lm

Power:

5,5 W

Colour temperature:

3500K

CRI:

CRI>90

Light beam angle:

34°

Lighting efficiency:

84%

Dimming:

DALI

Sealing:

IP20
NANO RECESSED FLOOD DALI 4000K N

Reference:

A5390212N

Colour:

Black

Light source:

LED

Luminous flux:

640 lm

Power:

5,5 W

Colour temperature:

4000K

CRI:

CRI>90

Light beam angle:

34°

Lighting efficiency:

84%

Dimming:

DALI

Sealing:

IP20
NANO RECESSED FLOOD DALI 4000K W

Reference:

A5390212W

Colour:

White

Light source:

LED

Luminous flux:

640 lm

Power:

5,5 W

Colour temperature:

4000K

CRI:

CRI>90

Light beam angle:

34°

Lighting efficiency:

84%

Dimming:

DALI

Sealing:

IP20

Are you interested in this product? Contact us

Instagram

This field is for validation purposes and should be left unchanged.

Name*

Surnames*

Email*

Phone*

Country*

City*

Company*

Profession*

Specify your profession*

Your message

I have read and agree to the privacy policy. *

I want to subscribe to the newsletter.

Company

This field is for validation purposes and should be left unchanged.

Name*

Surnames*

Email*

Phone*

Country*

City*

Your message*

I have read and agree to the privacy policy. *

I want to subscribe to the newsletter.

Nano

CEILING RECESSED

Nano Recessed

Luminous Flux

Power

Colour temperature

Lighting efficiency

CRI

Light beam angle

Dimming

Sealing

Cord length

Distance of suspension

Base Finishing

Colour

Are you interested in this product? Contact us

Related products

Shot Light

Swap

Lex

Olympia

Downloads

Downloads

Downloads

Downloads

Downloads

Downloads

Downloads

Downloads

Downloads

Downloads

Downloads

Downloads

Downloads

Downloads

Downloads

Downloads

Downloads

Downloads

Downloads

Downloads

Downloads

Downloads

Downloads

Downloads

Downloads

Downloads

Downloads

Downloads

Downloads

Downloads

Downloads

Downloads

CAD 2D/3D

Downloads
