Puck
SURFACE
Puck is designed to undertake general lighting functions and, moreover, given its ultra-compact format, aims to conserve discretion in those places where it is impossible to recess the appliances in the ceiling. Puck’s minimalist presence is formally summed up in a circular piece, entirely manufactured in aluminium.
Awards
-
Iconic Award Interior Innovation 2017 Winner
Puck S Remote
-
Luminous flux
710 lm / 760 lm / 770 lm / 800 lm
-
Lighting efficiency
72%
-
Power
5 W
-
Dimming
No Dim / DALI / Phase Cut
-
Colour temperature
2700K / 3000K / 3500K / 4000K
-
Sealing
IP20
-
Chromatic stability
MacAdam Step 2
-
Light beam angle
38°
-
Model
Ref.
Colour
Source
Lum. flux
Power
Temp.
CRI
Beam angle
Efficiency
Dimming
Sealing
-
Reference:
A5770000NT
Colour:Textured black
Light source:LED
Luminous flux:710 lm
Power:5 W
Colour temperature:2700K
CRI:CRI>90
Light beam angle:38°
Lighting efficiency:72%
Dimming:No Dim / DALI / Phase Cut
Sealing:IP20
-
Reference:
A5770000WT
Colour:Textured white
Light source:LED
Luminous flux:710 lm
Power:5 W
Colour temperature:2700K
CRI:CRI>90
Light beam angle:38°
Lighting efficiency:72%
Dimming:No Dim / DALI / Phase Cut
Sealing:IP20
-
Reference:
A5770001NT
Colour:Textured black
Light source:LED
Luminous flux:760 lm
Power:5 W
Colour temperature:3000K
CRI:CRI>90
Light beam angle:38°
Lighting efficiency:72%
Dimming:No Dim / DALI / Phase Cut
Sealing:IP20
-
Reference:
A5770001WT
Colour:Textured white
Light source:LED
Luminous flux:760 lm
Power:5 W
Colour temperature:3000K
CRI:CRI>90
Light beam angle:38°
Lighting efficiency:72%
Dimming:No Dim / DALI / Phase Cut
Sealing:IP20
-
Reference:
A5770003NT
Colour:Textured black
Light source:LED
Luminous flux:770 lm
Power:5 W
Colour temperature:3500K
CRI:CRI>90
Light beam angle:38°
Lighting efficiency:72%
Dimming:No Dim / DALI / Phase Cut
Sealing:IP20
-
Reference:
A5770003WT
Colour:Textured white
Light source:LED
Luminous flux:770 lm
Power:5 W
Colour temperature:3500K
CRI:CRI>90
Light beam angle:38°
Lighting efficiency:72%
Dimming:No Dim / DALI / Phase Cut
Sealing:IP20
-
Reference:
A5770002NT
Colour:Textured black
Light source:LED
Luminous flux:800 lm
Power:5 W
Colour temperature:4000K
CRI:CRI>90
Light beam angle:38°
Lighting efficiency:72%
Dimming:No Dim / DALI / Phase Cut
Sealing:IP20
-
Reference:
A5770002WT
Colour:Textured white
Light source:LED
Luminous flux:800 lm
Power:5 W
Colour temperature:4000K
CRI:CRI>90
Light beam angle:38°
Lighting efficiency:72%
Dimming:No Dim / DALI / Phase Cut
Sealing:IP20
